Operating Instructions
ACCUSPLIT® EAGLE
AE140XL
PEDOMETER
Functions
• Step counter.
• Distance in mi or km.
For complete Function Specifications, go to page 24.
Key Features
• Built around the Japanese-made JW200 PedometerEngine™
Step Sensor, the current gold standard for accuracy.
• Extra Large Digits.
• The ACCUSPLIT exclusive case makes this the slimmest
available pedometer built around the JW200 Step Sensor.
• Chromed, Spring Steel clip resists breakage.
• Case includes two leash slots, for attaching safety leash
on either side. Made from tough polycarbonate plastic.
• Step filter, can be set from 0-5 steps to further increase
accuracy.
HOW TO OPEN YOUR PEDOMETER
See diagrams at right.
The cover must be closed for the
pedometer to work.
USE IT NOW!
Your pedometer is preset with standardized settings
that allow you to use it now! You can customize the
settings later. Skip to pages 13-16 to use it now!
SETTING UP YOUR PEDOMETER
It’s a good idea to set up your pedometer before first using it.
To record your distance accurately, you will need to set your
stride length.
See page 9 when you are ready to set up your unit.
ACCUS PLIT EAGLE
DigiwalkerXL.com STEP TIME DIST CA L SET 4728
MODE
RESET
S3– S1, S2, S4 S3+
140S XL
Getting Acquainted
• Press the MODE button to cycle through the display
modes (Steps and distance.)
See page 16 and Specifications for details.
• The RESET button sets your counts back to zero.
See page 17 for details.
MODES
• STEP: STEP mode shows step count.
• DIST: DISTANCE mode shows distance traveled (mi/km).
STEP DIST SET
D IGI - W ALKER XL .COM
140 XL
S3- S3+ S1,S2,S4
JW200
Mode
indicator
Steps
Counted
MODE Button
RESET Button (yellow)
ACCUSPLIT, Inc.
3090 Independence Drive, Suite 148
Livermore, CA 94551 USA
800-935-1996 • 925-290-1900 • FAX 925-290-1930
www.ACCUSPLIT.com • [email protected]
Eat Right! Walk More! Live Well!
e ACCUSPLIT Lifestyle
970-086
Nov 07
