SW2 VGA DA2 A /AF • Introduction
Introduction, cont’d
SW2 VGA DA2 A /AF
2
Chapter Two
Installation and Operation
Installation Overview
Mounting the SW2 VGA DA2 A /AF
Front Panel Features
Rear Panel Features
Cabling
Operation
Troubleshooting
Introduction
About this Manual
This manual contains information about the Extron
SW2 VGA DA2 A and SW2 VGA DA2 AF switchers and details
on how to operate and configure them.
About the SW2 VGA DA2 A /AF
The SW2 VGA DA2 A /AF is a high performance, two-input
computer-video switcher with 300 MHz (-3 dB) video
bandwidth. It accepts two VGA-UXGA computer-video inputs
and two stereo audio inputs. It features two buffered VGA-
UXGA outputs and one stereo audio output. With an optional
Macintosh/VGA adapter, the SW2 VGA DA2 A /AF can also
switch and distribute Macintosh signals.
Front panel buttons, a contact closure controller, or the
autoswitching option can be used for input selection.
Features
Autoswitching ability — The SW2 VGA DA2 A /AF can detect
active sync signals and automatically switch to the active
input.
Rack shelf and furniture mountability — The SW2 VGA DA2 A
and SW2 VGA DA2 AF can be mounted on a rack shelf,
under a desk or podium with the included hardware, or it
can be mounted through a desk or other furniture with
optional vertical mounting brackets.
Stereo audio — Unbalanced stereo audio inputs can be output
as balanced or unbalanced stereo audio.
1-2
