40
Technical Support US: 888-443-2751 Technical Support INTL: 316-943-2751
VFD Control Box (Cover removed)
VFD Controller
Circuit Breaker
MUA Damper Relay
(R2) (optional)
MUA Damper Relay
(R3) (optional)
MUA Damper Relay
(R4) (optional)
Manual Mode
Relay (R5)
Manual Mode
Relay (R6)
Manual Mode
Relay (R7)
Manual Mode Switch #1
Grounding Block Terminal Strip (TS1)
Oven/hood interface
Terminal Strip (TS2)
Manual Mode Switch #2
VFD Control Box - Standard
