Conveyor Control Programming Procedure
OVEN SERVICE PROCEDURES
Read the entire instruction before programming.
Configuration Key Functions
< L > =
Behind the in XLT is a hidden button. This is used along with the up and down button to ac-
cess the programming mode. Use this after each step to advance to the next parameter when pro-
gramming.
UP = Increases the setting of the selected parameter.
Down = Decrease the setting of the selected parameter.
1. Enter Programming Mode/ Program the bake length

Press the button and both and button simultaneously to enter programming mode.
(You will be in bake length programming mode)

0055 will appear on screen, this is already set from factory

Press the button until the desired belt length is displayed for your application. Belt lengths will
read as follows:
1832 = 0032
1855 = 0055
2440 = 0040
3240 = 0040
3255 = 0055
3270 = 0070
3855 = 0055
3870 = 0070
3. Program the Total Reduction Value

Press the button until the desired settings is reached. All ovens = 300.
4. Set Speed Trimming Value

Press the button until the display shows 0000.
5. Set Fast Bake Limit

Press the button until the display shows 1:30.
6. Set Slow Bake Limit

Press the button until the display shows 17:00.
7. Set Conveyor Motor Rotation

Press the OR buttons until the display shows 1 for right-to-left direction, or 2 for left-to
-right belt direction.
8. Save and Exit Programming Mode

Press the button two times to save and exit Programming Mode.
9. 1:30 run time will appear

Press and hold the or buttons until desired run time appears.
