AVI HOOD INSTALLATION

69 5/8

+/- 1/8

[1768

+/- 3

]

All thread provided by others

NOTE

This measurement is from the finished floor to the bottom of the suspended hood.

Hood Must Be Suspended From Ceiling Joists

DANGER
