Oven Initial Start-up Checklist - Remove & Return to XLT Ovens
3rd step
:
Place all control boxes in service position and document settings, remove blue tag from
inside control box and connect switch to wire harness. Start each oven and complete form below.
Top Oven
Verify Existing Serial #
N/A
Model #: __________________________________
Serial #: __________________________________
Front Belt Speed: _______min ______sec
Back Belt Speed: _______min ______sec
N/A
Proper Belt Tension:
Yes
No
Conveyor Belt Direction:
L to R
R to L
Set Point Temp: Left ________ Right _________
Fingers in proper location:
Yes
No
Fire Suppression Installed:
Yes
No
Right Burner:
Shutter Setting:
High Bias: ___________ Low Bias: ___________
Flame Sense µA
Left Burner:
2B Ovens Only
Shutter Setting:
High Bias: ___________ Low Bias: ___________
Flame Sense µA
4th step
: Record dynamic pressure with all the gas appliances running.
Inlet Pressures: Dynamic: _______ Is WC within 6-14” WC
Yes
No, contact store owner to adjust. ____Initial
Middle Oven
Verify Existing Serial #
N/A
Model #: __________________________________
Serial #: __________________________________
Front Belt Speed: _______min ______sec
Back Belt Speed: _______min ______sec
N/A
Proper Belt Tension:
Yes
No
Conveyor Belt Direction:
L to R
R to L
Set Point Temp: Left ________ Right _________
Fingers in proper location:
Yes
No
Fire Suppression Installed:
Yes
No
Right Burner:
Shutter Setting:
High Bias: ___________ Low Bias: ___________
Flame Sense µA
Left Burner:
2B Ovens Only
Shutter Setting:
High Bias: ___________ Low Bias: ___________
Flame Sense µA
Bottom Oven
Verify Existing Serial #
N/A
Model #: __________________________________
Serial #: __________________________________
Front Belt Speed: _______min ______sec
Back Belt Speed: _______min ______sec
N/A
Proper Belt Tension:
Yes
No
Conveyor Belt Direction:
L to R
R to L
Set Point Temp: Left ________ Right _________
Fingers in proper location:
Yes
No
Fire Suppression Installed:
Yes
No
Right Burner:
Shutter Setting:
High Bias: ___________ Low Bias: ___________
Flame Sense µA
Left Burner:
2B Ovens Only
Shutter Setting:
High Bias: ___________ Low Bias: ___________
Flame Sense µA
