Appendix d serial port pin outs – Asante Technologies 3500 User Manual
Page 31
31
Asanté IntraCore 3500 Series
Appendix D Serial Port Pin Outs
The console port is used to connect with a terminal using a DB-9
female connector. The setting is 9600-N81. See the table below for
a list of pin outs.
Pin Number
Signal
Name
1
CD
Carrier Detect
2
RD
Receive Data
3
TD
Transmit Data
4
DTR
Data Terminal Ready
5
SG
Signal Ground
6
DSR
Data Set Ready
7
RTS
Request to Send
8
CD
Carrier Detect
9
RI
Ring Indicator
