Wade Antenna Tripods & NPRMS - Manual

DELHI Pop-Ups, Tripods & Accessories
Non-Penetrating Roof Mounts and Tripods
Non-Penetrating Roof Mounts
Pre-galvanized steel frame. •
Accommodates patio stones and concrete blocks. •
Heavy duty construction. •
Accepts up to 2.5” mast (mast not included). •
uPs shippable. •
NPRM-1 34 lbs (15.5 kg)
NPRM-2 50 lbs (22.73 kg)
min. mast Height 53” (includes 6” for mounting)
Base size for both: 48” (1.2 m) x 48” (1.2 m)
NPRM-1/2
mast height 36” (0.91 m) included, 26 lbs (11.8 kg), base size 48” x 30” (0.76 m)
NPRM-3
Accepts up to 2” mast, min. 49” mast height (includes 6” for mounting)
WAde AnTennA’s ongoIng PolIcy of conTInuIng develoPmenT mAy resulT In sPecIfIcATIon cHAnges To ITs ProducTs
www.wadeantenna.com
Tripod Roof Mounts
• 1 ¼” (3.18 cm) galvanized welded steel tubing.
• Accepts up to 1 ¾” (4.4 cm) mast.
• Heavy duty construction.
• swing away mast support.
TRM-3
TRM-3P
TRM-3PL
TRM-5
TRM-5P
TRM-5PL
TRM-10
PPLS
TR2-5
3 Tripod PipeB
.
3’ (0.91 m), 8 lbs (3.63 kg)
leg distance: 32”
As above individually packaged.
As above individually packaged including PPls.
5’ (1.52 m), 13 lbs (5.9 kg)
leg distance: 44”
As above individually packaged.
As above individually packaged including PPls.
10’ (3 m), 50 lbs (22.73 kg)
leg distance: 78”
Three butyl sealing pads.
six 2” (5.1 cm) lag screws.
Bi-pod. 5’ (1.52 m), 7 lbs (3.18 kg)
3 foot tripod packaged with 3 foot
1.66” o.d. mast, 14 ga
ROOF MA
TS NOW
AVAILABLE!
(NPRM-MA
T)
TR2-5
TRM-3
TRM-10L
Our 10 ft Tripod is ideal for
lighting and sound applications
* All tripods pre-assembled for quick and easy on-site installation
NEW
Supports
up to 12
blocks
NPRM-3
TRM-5
NPRM-1/2
