Wade Antenna PD2-2.4(Y) - Manual

Description
These power dividers allow more than one
antenna to be connected to a radio to help shape
RF signals for your wireless networks. Signal loss
from the dividers need to be considered when
added to your wireless access points. See our
electrical specifications below for more details.
2.4 GHz Power Dividers
Electrical
SPECIFICATIONS
Mechanical
WADE Antenna Inc.
29 Sharp Road
Brantford, Ontario, N3T 5L8 Canada
Tel: 519.756.7157
Fax: 519.756.5056
(800) 463-1607
[email protected]
www.wadeantenna.com
MODEL PD2-2.4
Frequency 2.4 – 2.5 GHz
Avg. Insertion Loss .25 dB
Max. Insertion Loss .5 dB
Max. VSWR 1.3:1
Max. Input Power 300 watts
Terminal Type ‘N’ female
Size (inches: L x W x H) 6.375 x 3.375 x 2.125
Weight 1.1 lbs. (0.5 kg.)
Material Zinc plated steel
WA D E A n t e n n a ’ s o n g o i n g p o l i c y o f c o n t i n u i n g d e v e l o p m e n t m a y r e s u l t i n s p e c i f i c a t i o n c h a n g e s t o i t s p r o d u c t s .
• PD2-2.4(T)
• PD2-2.4(Y)
