ELECTRICAL:
MECHANICAL:
WIND LOADING:
* Wind Speed = 100 MPH at sea level with One Hundred Percent Humidity at Seventy Degrees Fahrenheit.
** Wind Speed = 50 MPH at sea level with One Hundred Percent Humidity at Zero Degrees Fahrenheit.
*** Maximum Wind Speed at sea level with One Hundred Percent Humidity at Seventy Degrees Fahrenheit. Safety Factor of 1.65 included.
Temperature, barometric pressure and humidity to MIL-STD. 210C
Rain, salt-fog, sand, dust and fungus to MIL-STD. 810F, Omni-directivity: +/-0.5dB
Helical Antenna Specifications
* Weights are approximate values
* HN Connector 1,000 watts, LC Connector 2,000 watts also available.
www.tacoantenna.com
TACO Antenna
A d i v i s i o n o f W A D E A n t e n n a , I n c .
MODEL(S)
H-062
H-082
H-084
H-064A H-084A
H-104
H-124
H-065
H-085
H-105
Frequency Range (MHz)
120-150 120-150 240-320 225-400 225-400 240-320 240-320 300-520 300-520 300-520
Gain (dBic)
12.5
13.8
13.8
12.5
13.8
14.8
16
12.5
13.8
14.8
Axial Ratio (Helical Only)
1.17
1.13
1.13
1.17
1.13
1.1
1.08
1.17
1.13
1.1
Impedance
50
50
50
50
50
50
50
50
50
50
Polarization
Circular
Circular
Circular
Circular
Circular
Circular
Circular
Circular
Circular
Circular
Cross Pol. Rejection
20dB
20dB
20dB
20dB
20dB
20dB
20dB
20dB
20dB
20dB
Back to Front Ratio
23dB
24dB
24dB
23dB
24dB
25dB
26dB
23dB
24dB
25dB
VSWR:
Max
1.4
1.4
1.5
1.5
1.6
1.5
1.5
1.5
1.5
1.5
Typical
1.2
1.2
1.2
1.3
1.3
1.2
1.2
1.3
1.3
1.3
HPBW:
Horz.
45
40
40
45
40
35
33
45
40
35
Vert.
43
38
38
43
38
34
31
43
38
34
1st Sidelobe Suppression
11dB
12dB
12dB
11dB
12dB
13dB
14dB
11dB
12dB
13dB
* Std. Connector
N
N
N
N
N
N
N
N
N
N
Max. Input Power
500W
500W
500W
500W
500W
500W
500W
500W
500W
500W
Operating Temperature (
o
C)
- 40 to +70 - 40 to +70 - 40 to +70 - 40 to +70 - 40 to +70 - 40 to +70 - 40 to +70 - 40 to +70 - 40 to +70 - 40 to +70
Operating Temperature (
o
F)
-40 to +158 -40 to +158 -40 to +158 -40 to +158 -40 to +158 -40 to +158 -40 to +158 -40 to +158 -40 to +158 -40 to +158
NSN
-
-
-
-
-
-
5985-01-476-
0720
-
-
-
MODEL(S)
H-062
H-082
H-084
H-064A H-084A
H-104
H-124
H-065
H-085
H-105
Number of Outputs
1
1
1
1
1
1
1
1
1
1
Number of Elem. (Turns)
6
8
8
6
8
10
12
6
8
10
Overall Length (in.)
155
190
112
84
103
134
155
68
84
97
Helical Diameter (in.)
27.43
27.43
13.43
11.85
11.85
13.43
13.43
9.0
9.0
9.0
Ground Plane Diameter (in.)
72
72
57
35
35
57
57
36
36
36
Mounting Stub Length (in.)
23
23
23
23
23
23
23
23
22
23
Stub Diameter (in.)
2.87
2.87
2.87
2.87
2.87
2.87
2.87
2.87
2.87
2.87
Antenna Weight
73lbs.
82lbs.
39lbs.
24lbs.
38lbs.
44lbs.
49lbs.
25lbs.
29lbs.
33lbs.
* Total Shipping weight
250lbs.
330lbs.
164lbs.
124lbs.
146lbs.
199lbs.
235lbs.
94lbs.
114lbs.
134lbs.
Mounting Options
Type
Mast/Tripod Mast/Tripod Mast/Tripod Mast/Tripod Mast/Tripod Mast/Tripod Mast/Tripod Mast/Tripod Mast/Tripod Mast/Tripod
Az. Adjust
360deg.
360deg.
360deg.
360deg.
360deg.
360deg.
360deg.
360deg.
360deg.
360deg.
El. Adjust
90deg.
90deg.
90deg.
90deg.
90deg.
90deg.
90deg.
90deg.
90deg.
90deg.
MODEL(S)
H-062
H-082
H-084
H-064A H-084A
H-104
H-124
H-065
H-085
H-105
Wind Area:
(Sq. Ft.)
(No Ice)
4.9
6.53
2.5
2.05
2.17
3.13
3.75
1.07
1.43
1.79
(1/2” Radial Ice)
11.05
14.73
5.64
4.7
4.9
7.05
8.46
2.42
3.23
4.04
Wind Load
(Ft.-Lbs.)
* (No Ice)
932
1,643
344
221
259
530
755
73
128
199
** (1/2” Radial Ice)
606
1,068
223
145
169
344
491
48
83
129
Survival Rating: ***(No Ice)
143mph 140mph 239mph 280mph 275mph 191mph 159mph 513mph 388mph 311mph
