TA C O A n t e n n a’s o n g o i n g p o l i c y o f c o n t i n u i n g d e v e l o p m e n t m a y r e s u l t i n s p e c i f i c a t i o n c h a n g e s t o i t s p r o d u c t s .
TACO Antenna
A d i v i s i o n o f W A D E A n t e n n a , I n c .
OFT-2S OMni DirecTiOnal
Dual Array Antenna
ELECTRICAL
MODEL OFT-2S
Frequency (MHz) 108 - 118
Gain (dBi Minimum) 2 dBi (Main Lobe)
Polarization Horizontal
VSWR Less than 1.6:1
Terminal Type “N” Female
Terminal Impedence 50 Ohms
Maximum Power 40 Watts
MECHANICAL
MODEL OFT-2S
Height (Max) 71.50 in. (181.6)
Width (Max) 60.0 in. (152.4 cm)
Mount (Mast Diameter) 2 - 3 in. (3 in. u -bolt)
Weight 19.5 lbs (8.85 kg)
OFT-2S
OMNI-DIRECTIONAL
DUAL ARRAY ANTENNA
This antenna is based on TACO’s
commercial off-the-shelf OFT dual
array antenna.
SPECIFICATIONS
ELECTRICAL
FREQUENCY (MHz) 108-118
GAIN (dBi Nominal) 2 dBi (Main Lobe)
POLARIZATION Horizontal
VSWR Less than 1.6:1
TERMINAL TYPE “N” Female
TERMINAL IMPEDANCE 50 Ohms
MAXIMUM POWER 40 Watts
HEIGHT (Max) 71.50 in. (181.6 cm)
WIDTH (Max) 60.00 in. (152.4 cm)
MOUNT (Mast Dia) 2 to 3 in. (3 in. u-bolt)
WEIGHT 19.5 lbs (8.85 kg)
MECHANICAL
TACO
Communications, Inc.
TACO
Communications, Inc.
29 Sharp Road
P.O. Box 1206
Brantford, Ontario, CANADA
N3T 5T3
This antenna is based on TACO’s commercial
off-the-shelf OFT dual array antenna
Specifications
US And InTernATIOnAl SAleS AGenT CAnAdIAn SAleS OFFICe
TACO Antenna
A divsion of Wade Antenna, Inc.
29 Sharp Road,
Brantford, Ontario, N3T 5L8, Canada
Tel: 519.756.7157
Fax: 519.756.5056
[email protected]
TACO Antenna Sales Rep
Tel: 717.975.0885
Toll Free: 866.975.4433
Fax: 717.763.0469
Email: [email protected]
Web Site: www.tacoantenna.com
