ELECTRICAL:
MECHANICAL:
WIND LOADING:
* Wind Speed = 100 MPH at sea level with One Hundred Percent Humidity at Seventy Degrees Fahrenheit.
** Wind Speed = 50 MPH at sea level with One Hundred Percent Humidity at Zero Degrees Fahrenheit.
*** Maximum Wind Speed at sea level with One Hundred Percent Humidity at Seventy Degrees Fahrenheit. Safety Factor of 1.65 included.
* Weights are approximate values
Rain, salt-fog, sand, dust and fungus to MIL-STD. 810F
Temperature, barometric pressure and humidity to MIL-STD. 210C
MODEl(S)
D5061A1 D5062A D5071
D5072
D5073
D5074
D5076
D5077
D5078
Frequency Range (MHz)
V 118-136 U 225-400
U 225-400
V 118-136
V 118-136
U 225-400
V 118-136
U 225-400 V 118-136 U 225-400 U 225-400
Gain (dBi) +0dB/-1dB
4.0
4.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
Number of Outputs
1
1
3
2
2
2
1
1
3
Number of Elements
2x V
2x U
U / V / U
V / V
U / V
U / U
V
U
U / U / U
VSWR:
Max
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.9
Typical
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
HPBW:
Horz.
360
360
360
360
360
360
360
360
360
Vert.
40
40
75
75
75
75
75
75
75
Polarization
Vertical
Vertical
Vertical
Vertical
Vertical
Vertical
Vertical
Vertical
Vertical
1st Sidelobe Suppression
13 dB
13 dB
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Cross Pol. Suppression
20 dB
20 dB
20 dB
20 dB
20 dB
20 dB
20 dB
20 dB
20 dB
Isolation
N/A
N/A
> 30 dB
>30 dB
>30 dB
>30 dB
N/A
N/A
>30 dB
Impedence
50
50
50
50
50
50
50
50
50
Std. Connector (female)
N
N
N
N
N
N
N
N
N
Max. Input Power
600W
500W
250W
350W
250W
250W
350W
250W
250W
Operating Temperature (o F)
- 40 to +158 - 40 to +158 - 40 to +158 - 40 to +158 - 40 to +158 - 40 to +158 - 40 to +158 - 40 to +158 - 40 to +158
DC Ground
YES
YES
YES
YES
YES
YES
YES
YES
YES
NSN
5985-01-050-
7525
5985-01-296-
1904
-
5985-01-053-
5108
5985-01-050-
7524
5985-01-050-
7523
5985-01-050-
7522
5985-01-050-
7521
-
MODEl(S)
D5061A1 D5062A D5071
D5072
D5073
D5074
D5076
D5077
D5078
Overall Length (in.)
121.5
69.5
111.5
153.0
85.0
85.0
55.5
30.5
121.5
Antenna Weight
19.0 lbs
13.5 lbs
17.0 lbs
17.0 lbs
12.0 lbs
12.0 lbs
6.0 lbs
5.0 lbs
17.0 lbs
* Total Shipping weight
23.5 lbs
15.0 lbs
19.0 lbs
22.0 lbs
14.0 lbs
14.0 lbs
10.0 lbs
8.0 lbs
19.0 lbs
Mounting Options
Type
Mast
Mast
Mast
Mast
Mast
Mast
Mast
Mast
Mast
Mast Size (O.D.)
2.875”
1.66” or
2.875”
2.875”
2.875”
2.875”
2.875”
1.66” or
2.875”
1.66” or
2.875”
2.875”
MODEl(S)
D5061A1 D5062A D5071
D5072
D5073
D5074
D5076
D5077
D5078
Wind Area:
(Sq. Ft.)
(No Ice)
1.31
0.56
1.21
1.64
0.68
0.68
0.46
0.28
1.31
(1/2” Radial Ice)
1.90
0.90
1.72
2.34
1.09
1.09
0.74
0.44
1.90
Wind Area:
(Ft-Lbs at mast)
* (No Ice)
248.7
51.6
206.0
407
81.3
81.3
31.2
6.9
248.7
**(1/2” Radial Ice)
103.4
24.4
85.7
169.2
38.4
38.4
14.7
3.3
103.4
Survival Rating: ***(No Ice)
140mph 140mph 150mph 140mph 135mph 135mph 150mph 150mph 150mph
D5000 Antenna
Specifications
www.tacoantenna.com
TACO Antenna
A d i v i s i o n o f W A D E A n t e n n a , I n c .
