CBPS-300 OPERATING INSTRUCTIONS
7
Table 2.0 Functional Descriptions of the CBPS-300 Controls and Indicators
Fig. 1
Index
Panel Markings Functional Descriptions
1 NONE
OPEN coil voltage positive terminal. Female,
Red connector jacks used for connecting voltage
test leads.
2 NONE
OPEN coil voltage negative terminal. Female,
Black connector jacks used for connecting
voltage test leads.
3 NONE
CLOSE coil voltage positive terminal. Female,
Red connector jacks used for connecting voltage
test leads.
4 EXT TRIGGER
External trigger input for remote control. This
input is to be used with the Vanguard
Instruments Company circuit breaker timers.
Female, 4 pin connector.
5 NONE
CLOSE coil voltage negative terminal. Female,
Black connector jacks used for connecting
voltage test leads.
6 NONE
MOTOR voltage positive terminal. Female, Red
connector jacks used for connecting voltage test
leads.
7 NONE
MOTOR coil voltage negative terminal. Female,
Black connector jacks used for connecting
voltage test leads.
8 FAULT
RESET
Fault LED. Led is lit when over current is
detected.
RESET switch. Reset fault condition and ready
CBPS-300 for next operation.
9 NONE
LCD; 2-line by 16-character; back-lighted;
Displays coil/motor voltages.
10
120/240 Vac, 8A, 50- 60 Hz
Input power connector with third-wire safety
ground and 10A built-in circuit breaker
11 NONE
Safety Ground. A 5/16 threaded stud with hand-
turned wing nut. This must be connected to the
station ground before connecting any CBPS-300
test leads to the transformer.
