NBOX(B)/PNC2 Printer Node Controller Installation Instructions TG200266 Issue 1/C 21/07/04
Installation Instructions - Fixing
NBOX(B)/PNC2
T X
R X
O K
D T R B
D T R A
C T S B
C T S A
T
T
R
R
X
T
T
R
R
T -
T +
R -
R +
L A N A
e a r t h b u s
T X
R X
O K
D T R B
D T R A
C T S B
C T S A
J1
3
J1
2
1.3 Installation - Fixing
(continued)
Connecting Power
(continued)
5
~
2 3 0 V
R D S / R S 2 3 2
!
2 4 V
~
M O D E M
T X
R X
O K
D T R B
D T R A
C T S B
C T S A
J1
3
J1
2
/24
24 Vac or 24 Vdc
NBOX/PNC2/24 consumption < =7.5 VA
WARNING: This apparatus must be earthed.
(via green earth wire)
DO NOT APPLY
POWER
0
I
24 V versions
Connect Trend Lan (Lan A)
6
T R
T R
T R
T R
T
T
R
R
T -
X
T +
R -
R +
L A N A
e a r t h b u s
T R
T R
T R
T R
2 wire
Network Engineering Manual, 92-1735.
additional terminals
Polarity independent
4 wire
Earth the
bus bar
Connect to Printer
8
~
2 3 0 V
R D S / R S 2 3 2
!
2 4 V
~
M O D E M
25 Way D type, Male
25 Way D type, Male
25 Way D type Male to
Male Cable, pins 3, 7, 20
connected straight through
cable not supplied with unit
(RS232 Port)
Select Printer
7
(Device B - RS232)
Printer must:
• Be able to accept Epson type control codes
• Have an RS232 serial interface with following settings:
Baud Rate: 19k2, 9k6, 4k8 or 1k2
Serial/Parallel: Serial
Comms type: either
8 bits no parity
or
7 bits odd parity
Auto Line Feed: On
The PNC2 must have its baud rate and comms type set
accordingly, see NBOX & NBOXB/PNC2 installation
instructions Sheet 2: Configuration steps 7 and 8.
