PACK/LNC2/STD Installation Instructions TG200240 Issue 3 09/07/08 5
Installation Instructions PACK/LNC2/STD
3 Installation
(continued)
Connect LNC2 to Wallbox 15
R S 2 3 2
L O N
L O N
O K
S E R V I C E
L A N O K
L N C 2
L A N
LNC2 LAN 9 Way D type
Female (cable)
Switch on PC 16
O
I
Cable supplied
Connect LNC2 Cable
to Wallbox
14
Assemble Wallbox
13
Remove Cutout
(as appropriate)
11 12
Route Cable
