PACK/LNC2/STD Installation Instructions TG200240 Issue 3 09/07/08
3
Installation Instructions
PACK/LNC2/STD
Mount Wallbox Base
Connect RS232, PC (COM port) to LNC2
6
R S 2 3 2
L O N
L O N
O K
S E R V I C E
L A N O K
L N C 2
L A N
PC (COM port) 9 Way D type female (cable)
LNC2 (RS232) RJ11 Male (cable)
Cable supplied
7
a
b
c
Dis-assemble Wallbox
3
Installation
(continued)
Fit the LNC2 into the PC
5
PACK/LNC2/STD/USA. The unit is UL rated as
‘UL916, accessory to open energy management
equipment’.
Follow PC manufacturer’s instructions for fitting
an expansion card
LA
N
T
X
LA
N
R
X
LA
N
B
U
S
Y
P
C
B
U
S
Y
L A N O K
L A N
S W 1
S W 2
LNC2
PCI bus
8
60 mm (2.36”)
40 mm
(1.57”)
45 mm (1.77”)
