IQLROUTER/230 Installation Instructions - Sheet 1
IQLROUTER/230 Installation Instructions TG200792 Issue 1/A 1/7/04 1 - 4
1.3 INSTALLATION - FIXING (Continued)
Connect Power
7
O N O F F
O F F B U S F R E E O F F B U S F R E E
1 2 3 4 5 P K T
2 4 V
6 7 8 9 1 0 1 1 1 2 1 3
L O N - A L O N - B
A - S V C - B 2 3 0 V A C
2 3 0 V a c
L N
3
E
1 2
Clean earths consisting of short (<300 mm,
12”) stranded copper wire (>=1.5 mm
2 ,
16 AWG) to a substantial earthed metal part
(e.g. cable tray) are recommended.
WARNING: This apparatus must be
earthed (via earth terminal).
SET Lon Terminator Links
6
OFF
No terminator. Lon must be
terminated elsewhere.
FREE
Use to terminate Lon at
IQL Router
O N O F F
O F F B U S F R E E O F F B U S F R E E
1 2 3 4 5 P K T
2 4 V
6 7 8 9 1 0 1 1 1 2 1 3
L O N - A L O N - B
A - S V C - B 2 3 0 V A C
O F F F R E E
O F F F R E E
Terminate Lon bus at one point only
Sheet 2
IQLROUTER/230 Installation Instructions - Sheet 2
2
Close Hinged Cover
8
a b
9
DO NOT
Switch on
230Vac supply
IQLROUTER/230 consumption = 2VA Terminal size 0.5 to 2.5 mm 2 (14 to 20 AWG)
