Figure 1, Dash board template, Figure 3 control switch connections – Audiovox CCS-203 User Manual
Page 3: Figure 2, Control switch mounting
Figure 1
Drill1/4"Dia.holes,(2places).
Carefullycut-outalongdotted
linesandplaceonselectedarea.
DASH BOARD TEMPLATE
Useafileorrazorknifetoremove
thematerialbetweenthe2holes.
Figure 3
CONTROL SWITCH CONNECTIONS
CRUISE
CONTR
OL
Figure 2
RED
CONNECTOR
1
2
3
4
GRE
EN
BRO
WN
YELL
OW
ACCE
L
O N
O F
F
S E
T
COAS
T
R E
S
DASH
CONTROLSWITCH
TEMPLATECUT-OUT
CONTROL SWITCH MOUNTING
