Table of Figures
Figure 1. Compliance Load Board for 1, 4, 8 and 16 lane connectors (CLB1). ..................................... 2
Figure 2. Compliance Base Board for 1, 4, 8 and 16 lane connectors (CBB1). .................................... 3
Figure 3. Compliance Load Board for 1 and 16 lane connectors (x1/x16 CLB2). ................................. 3
Figure 4. Compliance Load Board for 4 and 8 lane connectors (x4/x8 CLB2). ..................................... 4
Figure 5. Compliance Base Board for 4 and 8 lane connectors (CBB2). .............................................. 4
Figure 6 - QualiPHY framework dialog and Standard selection menu. ................................................. 8
Figure 7 - The Test Report Summary and Details pages. ...................................................................... 11
Figure 8 – X-Replay Mode window. ......................................................................................................... 15
Figure 9 - The Skew parameter right side dialog, Skew clock 2 tab, showing default setup. ........... 24
About This Manual
This manual assumes that you are familiar with using an oscilloscope
−in particular the Teledyne
LeCroy oscilloscope that will be used with QualiPHY
−and that you have purchased the QPHY-
PCIE software option. Some of the images in this manual may show QualiPHY products other
than QPHY-PCIE, or were captured using different model oscilloscopes, as they are meant to
illustrate general concepts only. Rest assured that while the user interface may look different
from yours, the functionality is identical.
