1-24 Chapter 1: Product introduction
3. Serial ATA connectors (7-pin SATA1, SATA2)
These connectors support the thin Serial ATA cables for Serial ATA
hard disks. If you installed Serial ATA hard disks, you may create a
RAID 0, RAID 1, or JBOD configuration.
Install the Windows ® 2000 Service Pack 4 or the Windows ® XP Service
Pack1 before using Serial ATA.
For detailed instructions on how to configure RAID 0, RAID1, and JBOD,
refer to the RAID manual in the support CD.
A8V-VM SE SATA Connectors
SATA 2
G
ND
RS
AT
A_
TX
P2
RS
AT
A_
TX
N2
G
ND
RS
AT
A_
RX
P2
RS
AT
A_
RX
N2
G
ND
SATA 1
G
ND
RS
AT
A_
TX
P1
RS
AT
A_
TX
N1
G
ND
RS
AT
A_
RX
P1
RS
AT
A_
RX
N1
G
ND
R
A8V-VM SE
4. Speaker out connector (4-pin SPEAKER)
This connector is for the case-mounted speaker and allows you to
hear system beeps and warnings.
A8V-VM SE Speaker Out Connector
SPEAKER
+5V
1
GND
Speak Out
GND
R
A8V-VM SE
