Instruction Manual
922175-00 Rev A 11
Adjustment Procedure
This procedure can be used to adjust the warranted characteristics of the CP150 Current Probe. This
procedure should be used if a parameter measured in the Performance Verification Procedure is outside
of the specification limits. Adjustment should only be performed by qualified personnel.
The warranted characteristics of the CP150 Current Probe are valid at any temperature within the
Environmental Characteristics listed in the Specifications. However, some of the other test equipment
used to verify the performance may have environmental limitations required to meet the accuracy
needed for the procedure. Make sure that the ambient conditions meet the requirements of all the test
instruments used in this procedure.
NOTE: The correct operation of the controls of the CP150 requires oscilloscope software version 4.3.0.0
or higher. The software version in the test oscilloscope can be verified by selecting Utilities, Utilities
Setup, then the Status tab. Contact your local Teledyne Lecroy representative if the software in your
oscilloscope requires updating.
Test Equipment Required
The following table lists the test equipment and accessories, or their equivalents, which are required for
adjustment of the CP150 Current Probe.
Because the input and output connector types may vary on different brands and models of test
instruments, additional adapters or cables may be required.
Table 2. List of required equipment.
Description Minimum Requirements Test Equipment Examples
Wide Band Oscilloscope ProBus interface equipped
Software version 4.3.0.0 or higher
Teledyne LeCroy LT322
Digital Multimeter (2 required) DC: 0.1% Accuracy
5½ digit resolution
Agilent Technologies 34401A, or
Fluke 8842A-09
Function Generator 50 Hz sine wave output
3 Vrms into 50 Ω Agilent Technologies 33120A, or
Stanford Research Model DS340
Calibration Fixture, 500 Turn Loop 5 00 Turn loop in series with 0.5 Ω
±0.1% resistor with sense terminals
Teledyne LeCroy CP150-CF02
Banana Plug Adapter Female BNC to Dual Banana Plug Pomona 1269
Calibration Fixture ProBus Extension Cable Teledyne LeCroy PROBUS-CF01
