MXs-B, Xi/Xi-A, Zi Oscilloscope System Recovery Instructions

selections.

11. A summary window is displayed indicating that Acronis

True Image is ready to proceed with the recovery of the C:
partition. Click Proceed to start the recovery process.

Note: This takes approximately 4 to 15 minutes depending
on the version of operating system that is being restored.
The progress is displayed on the screen.

12. Once the restoration is complete, an Information dialog is

displayed indicating that the Data was successfully
restored. Click OK.

13. From the Acronis menu bar, choose Operations > Exit. The

oscilloscope will restart and begin installing the required
software.

Reinstall the Oscilloscope Application

1. When the X-Stream DSO Setup Wizard appears, click Next.

2. On the License Agreement page, select I Agree.

3. On the Choose Components page, select the default

(installation) and click Install.

NOTE: You may see a Windows Security message indicating
that Windows can't verify the publisher of the driver
software. Choose "Install this driver software anyway" and
click Install.

4. When the X-Stream installation is complete, choose to

Reboot now and click Finish.

5. When prompted, enter your Windows Product Key number to

re-activate Windows.

Reactivate the F11 Startup Utility

Echo Workstation users can skip this procedure and go on to
restore to current levels.

In order for the system recovery wizard to be accessed again
from the boot menu, you must reactivate the F11 startup utility.
It is critical to complete these steps after your oscilloscope has
restarted.

1. From the Windows Start Menu choose All Programs >

Acronis > Acronis True Image Home.

2. On the Acronis True Image Home window, towards the top

right, click Tools & Utilities.

3. On the Tools & Utilities page, beneath Protection Tools, click

Acronis Startup Recovery Manager.

4. On the Acronis Startup Recovery Manager window, click

Activate. F11 boot time recovery is now enabled.

NOTE: The process "Searching for Acronis Secure Zone…"
may take several minutes.

Restore Software to Current Revision Levels

The recovery process produces a replica of the operating system
and oscilloscope application software at the revision levels that
were current when the oscilloscope was manufactured. It does
not automatically upgrade the:

l

Oscilloscope application software (X-Stream)

l

Windows operating system

l

Virus scan definition files

l

Drivers for some hardware options and accessories

Therefore, after completing the disk image recovery, it is highly

recommended to search vendor websites and upgrade the
individual components to current revision levels.

The latest oscilloscope application software can be downloaded
directly from the Teledyne LeCroy website at teledynelecroy.com.
Most required hardware drivers can be installed during the
firmware upgrade.

Since the calibration data for the oscilloscope is stored in the D:
drive, current calibration constants are not overwritten during
recovery of the C: drive. You do not need to restore these.

923605 Rev B

2
