3

PRODUCT FEATURES

The purpose

of this booklet is to provide assembly,

installation and operation information concerning the 6000

Series Residential Garage Door Openers and related Accessory

Products.

NOTICE

IT IS IMPORTANT THAT THIS INSTRUCTION

MANUAL BE READ AND UNDERSTOOD

COMPLETELY BEFORE INSTALLATION OR

OPERATION IS ATTEMPTED.

NOTICE

THE IMPORTANT SAFEGUARDS AND

INSTRUCTIONS IN THIS MANUAL CANNOT

COVER ALL POSSIBLE CONDITIONS AND

SITUATIONS WHICH MAY OCCUR DURING ITS

USE. IT MUST BE UNDERSTOOD THAT

COMMON SENSE AND CAUTION MUST BE

EXERCISED BY THE PERSON(S) INSTALLING,

MAINTAINING AND OPERATING THE

EQUIPMENT DESCRIBED HEREIN. DO NOT

USE THIS EQUIPMENT FOR ANY OTHER THAN

ITS INTENDED PURPOSE - OPERATING

OVERHEAD GARAGE DOORS.

STANDARD FEATURES:

Sensing System:

A built-in sensing system detects

obstructions during door operation. If in the downward (close)

travel mode, the Opener will sense an obstruction and reverse

the direction of the door. In the open mode, the Opener will

stop. Since all doors are different, the Sensing System has

independent adjustments for customizing the level of force

required for the normal opening and closing of specified doors.

( Page 18)

Close Limit Switch:

In winter months it's common for

small pieces of ice or packed snow to be trapped under the

door. Ground swelling can also effect the close limit setting of

the Opener. The 6000 Series Close Limit Switch overrides the

Sensing System during the last one inch of closing travel and

prevents the door from reversing if it encounters an obstruction

at this point.

Alternating Action Operation: The mechanical wall

pushbutton functions in an Open/Stop/Close/Stop & Reverse

mode in normal operation. (Page 16)

Emergency Release:

A pull cord allows separation of the

drive mechanism and manual operation of the door when

desired, as in the event of a power failure. (Page 11)

Automatic Reconnection:

Once power is restored, or

automatic operation of the door is again desired, initiating

operation in the normal manner (Push Button, Radio Control,

etc.) will effect automatic reconnection of the Emergency

Release Mechanism. (Page 11)

Connections For Continuously Monitored Auxiliary

Entrapment Protection Devices:

The 6000 Series

All-Clear™ Photosystem (light beam across the door

opening) can be easily connected to the Opener. Control

circuitry monitors the device continuously for proper

operation. (Page 20) Consult the factory for

compatibility of other auxiliary entrapment protection

devices.

Constant Contact To Close:

For utmost safety, the

standard operation mode requires constant contact on the

mechanical Push Button to close the door if an Auxiliary

Entrapment Protection Device (see above) IS NOT

installed or if the Device fails. In this mode of

operation, a Radio Transmitter cannot be used to close

the door. (Page 13 & 14)

Momentary Contact To Close:

After installing an

All-Clear™ Photosystem Auxiliary Entrapment

Protection Device the close operation mode is

automatically converted to momentary contact of the

mechanical Push Button, and a portable Radio

Transmitter can be used to close the door. (Page

Z

16)

A

ll-Clear™ Photosystem:

An invisible infrared

beam of light guards the door opening and reverses a

downward moving door if the beam is broken by a

stationary or moving object. The 6000 Series motor

control circuitry constantly monitors the All-Clear

Photosystem for proper operation.

OPTIONAL FEATURES:

Digital Radio Controls:

The 6000 Series Openers

covered in this Manual can be fitted with optional Radio

Controls. Up to 19,683 private codes can be easily

selected without use of tools. (Page

Z

15)

Super Station (Deluxe Wall Push Button):

A

feature-packed accessory unit, the Super Station allows

access to all of the Opener's functions. Independent

Open, Close, and Stop buttons permits full control of the

door’s operation. The Opener's built-in light can be

turned on or off independent of door operation. A

Security Switch allows the Opener to be deactivated for

extended periods of time. A Security Disable switch is

provided if the garage door is the only entryway into the

garage. Lighted Push Buttons enhance nighttime use.

(Page 16)

Keyless Entry System:

A tamper resistant outdoor

keypad, the optional Keyless Entry System permits entry

to the garage without use of key or radio transmitter.

Easily programmable, it accommodates four separate

access codes of 4 digits. Lighted Buttons enhance

nighttime use.
