I N S T A L L A T I O N A N D O W N E R ’ S M A N U A L
As of date of manufacture,
meets all ANSI/UL 325 Safety
Requirements for Vehicular
Garage Door Openers
Residential Vehicular Garage Door Opener
Model MVP-SB SUPER BELT
R E A D T H I S M A N U A L C A R E F U L L Y B E F O R E I N S T A L L A T I O N O R U S E
104334
INSTALLER: Place this manual in the plastic envelope provided and
permanently attach to the wall near the pushbutton.
Product Features ................................................... 2
Component Identification ..................................... 3
Identify Your Door Type ........................................ 3
Important Installation Instructions........................ 4
Assembly Instructions........................................... 5
Installing the Opener ............................................. 7
Mounting the Front Bracket ................................ 7
Mounting the Power Head ................................... 7
Power Requirements/Permanent Wiring ............ 8
Control and Auxiliary Equipment.......................... 9
Installation of the Super Station ......................... 9
Standard Wall Push Button Installation ............. 9
Installation of Safe Finish Photosystem........... 10
Important Safety Instructions ........................... 11
Installation Checklist ........................................... 12
TABLE OF CONTENTS
WARNING
Indicates a
MECHANICAL
hazard of INJURY
OR DEATH. Gives
instructions to avoid
the hazard
.
Operation and Adjustment Instructions..............12
Basic Operating Parameters..............................12
Door Arm Connection ........................................13
Programming The Radio System ......................14
FCC and IC Radio Operation Statement ..........15
Testing the Limit Settings..................................16
Testing the Sensitivity .......................................16
Testing the Reversing System ..........................16
Testing the Safe Finish Photosystem ...............17
Operating the Super Station ..............................17
Wiring Diagram.....................................................18
Using the Manual Release Mechanism ...............19
Troubleshooting Guide ........................................19
Warranty Statement..............................................20
CAUTION
READ THESE STATEMENTS CAREFULLY AND FOLLOW THE INSTRUCTIONS CLOSELY
The Warning and Caution boxes throughout this manual are there to protect you and your equipment.
Pay close attention to these boxes as you follow the manual.
WARNING
