background image

Page 20

For technical questions, please call 1-800-444-3353.

SKU 68001

Part

description

Qty

1

Spray Gun

1

2

Paint Hose

1

3

Base Frame

1

4

Hex Bolt (M6x4)

2

5

Pressure Relief Valve Label

1

6

Housing Cover

1

7

Output Gear Bushing

2

8

Rolling Bearing

1

9

Output Pole

1

10

Gear

1

11

Middle Gear Bushing

2

12

Output Gear

1

13

Pin (5x12)

2

14

Screw

1

15

Paint Outlet

1

16

O-Ring (10x1.8)

1

17

Output Spring

1

18

Mandrel

1

19

Steel Ball (6.4)

1

20

Seal Seat

1

21

Output Pusher

1

22

Pump Body

1

23

Nylon Washer

1

24

Insert Block

1

25

Pressure Relief Valve

1

26

Nylon Ring

1

27

O-Ring (5x1.8)

1

28

Pressure Relief Pole

1

29

Pressure Relief Spring

1

30

Spring Seat

1

31

Pin (3x8)

1

32

Control Valve Seat

1

33

Prime/Spray Valve

1

34

Pin

1

35

Nylon Cable Tie

1

36

Inlet Spring Holder

1

37

Input Spring

1

38

Steel Ball (12.7)

1

39

Input Seal

1

40

Input Washer

1

41

O-Ring (17x1.8)

1

42

Paint Input Adaptor

1

43

Pressure Relief Plug

1

44

Small Clamp

1

45

Large Clamp

1

46

Return Tube

1

47

Suction Tube

1

48

Clip

3

49

Inlet Pipe Lock Ring

1

50

Filtrate Seat Assembly

1

51

Wire label

1

52

Power Cord

1

53

Locking Ring

1

54

Screw (M4x14)

2

Part

description

Qty

55

Wire Fastening Seat

1

56

Label

1

57

Hex Bolt (M6x10)

3

58

Housing

1

59

Label

1

60

Motor Assembly

1

61

Power Switch

1

62

Pin (3x12)

1

63

Hex Bolt (M5x14)

4

64

Elastic Washer

4

65

O-Ring (12.5x2.65)

2

66

Joint Stopper

1

67

Position Washer

1

68

Wave Washer

1

69

White Seal

3

70

Black Seal

2

71

Copper Washer

1

72

O-Ring (22.5x1.8)

2

73

Connector

1

74

Copper Guide Bushing

1

75

Piston

1

76

Lock Sleeve

1

77

White Seal

2

78

Pressure Control Pin

1

79

O-Ring (8.8x1.9)

1

80

O-Ring (27x2.4)

1

81

Hex Bolt (M3x10)

1

82

Pressure Seal Cover

1

83

Micro Switch

1

84

Micro Switch Cover

1

85

Pressure Control Switch

1

86

Switch Cover

1

87

Pressure Adjusting Spring

1

88

Spring Pusher

1

89

Pressure Control Label

1

90

Pressure Knob

1

91

Pressure Control Bolt

1

92

Label

1

93

Handle Grip

1

94

Handle

1

95

Hex Bolt (M6x30)

2

96

PCB Supporter

1

97

Wire Connector

1

98

Nylon Cable Tie

1

99

Safety Cover

1

100 PCB Assembly

1

101 Tapping Screw

2

102 Power Cord Fixer

1

103 Hex Bolt (M4x20)

2

104 Cup

1

105 Bolt (M5x20)

1

106 Pole Stopper

1

107 Small Gear Washer

1

Parts list
