New Hardware Supported
page 8 OmniSwitch 6800/6850/9000—Release 6.1.3.R01
100FX Ethernet Transceivers
SFP-100-BX20LT - 100Base-BX SFP transceiver with an SC type interface. This bi-directional trans-
ceiver is designed for use over single mode fiber optic on a single strand link up to 20KM point-to-point.
This transceiver is normally used in the central office (OLT) transmits 1550nm and receives 1310nm opti-
cal signal.
SFP-100-BX20NU - 100Base-BX SFP transceiver with an SC type interface. This bi-directional trans-
ceiver is designed for use over single mode fiber optic on a single strand link up to 20KM point-to-point.
This transceiver is normally used in the client (ONU) transmits 1310nm and receives 1550nm optical
signal.
SFP-100-LC-MM - 100Base-FX SFP transceiver. Supports multi mode fiber over 1310nm wavelength
(nominal) with an LC connector.
SFP-100-LC-SM15 - 100Base-FX SFP transceiver. Supports single mode fiber over 1310nm wavelength
(nominal) with an LC connector. Typical reach of 15 Km.
SFP-100-LC-SM40 - 100Base-FX SFP transceiver Supports single mode fiber over 1310nm wavelength
(nominal) with an LC connector. Typical reach of 40 Km.
Supported Configuration Matrix for New Ethernet Transceivers
The following table shows the Ethernet transceiver configurations supported with the 6.1.3.R01 release:
SFP
OS6800/OS6850
Combo Ports
OS6800-U24
Non-Combo
Ports
OS6850-U24X OS9-GNI-U24
SFP-GIG-T - 1000Base-T Giga-
bit Ethernet Transceiver (SFP
MSA). supported supported supported supported
SFP-DUAL-MM - Dual Speed
100Base-FX or 1000Base-X Ether-
net optical transceiver. unsupported unsupported supported supported
SFP-DUAL-SM10 - Dual Speed
100Base-FX or 1000Base-X Ether-
net optical transceiver (SFP MSA) unsupported unsupported supported supported
SFP-100-BX20LT - 100Base-BX
SFP bi-directional transceiver. unsupported unsupported supported unsupported
SFP-100-BX20NU - 100Base-BX
SFP bidirectional transceiver. unsupported unsupported supported unsupported
SFP-100-LC-MM - 100Base-FX
SFP transceiver. unsupported unsupported supported unsupported
SFP-100-LC-SM15 - 100Base-FX
SFP transceiver. unsupported unsupported supported unsupported
SFP-100-LC-SM40 - 100Base-FX
SFP transceiver. unsupported unsupported supported unsupported
