Connecting XR 6412 Storage
The following diagrams illustrate 2-loop and 4-loop connections for XR 6412 series storage assemblies.
A XR 6412 RAID enclosure supports a maximum of seven XE expansion enclosures. Configurations with
two XR RAID enclosures are not supported.
WARNING Do not power on your storage before installing Linux, otherwise the Red Hat installer might attempt
to format the storage array and use it as the system disk.
Cabling for additional enclosures
XE (EBOD) Expansion Enclosure
0
1
0
ID
0
1
0
ID
XR RAID Enclosure
0
!
0
!
FACTORY
USE ONLY
FACTORY
USE ONLY
XE (EBOD) Expansion Enclosure
0
1
0
ID
0
1
0
ID
XE (EBOD) Expansion Enclosure
0
1
0
ID
0
1
0
ID
XE (EBOD) Expansion Enclosure
0
1
0
ID
0
1
0
ID
To FC adapter on workstation / LMS (port 1)
To FC adapter (port 2)
Single XR 6412 RAID enclosure, 2 loops
