Connecting XR 6500 Storage
The following diagrams illustrate 2-loop and 4-loops connections for XR 6500 series storage assemblies.
Cable your storage exactly as illustrated to ensure proper functionality.
A XR 6500 RAID enclosure supports a maximum of seven XE expansion enclosures. Configurations with
two XR RAID enclosures are not supported.
WARNING Do not power on your storage before installing Linux
®
, otherwise the Red Hat
®
installer might attempt
to format the storage array and use it as the system disk.
I
0
I
0
0
0
0
0
0
0
I
0
I
0
HOST 1
8
4
1/2
HOST 0
8
4
1/2
C
A
S
HOST1
8
4
1/2
HOST0
8
4
1/2
C
A
S
I
0
I
0
0
0
0
0
0
0
I
0
I
0
0
0
0
0
0
0
I
0
I
0
0
0
0
0
0
0
XR RAID Enclosure
XE (EBOD)_Expansion Enclosure
XE (EBOD) Expansion Enclosure
XE (EBOD) Expansion Enclosure
XE (EBOD) Expansion Enclosure
Single XR 6500 RAID enclosure, 2 loops
To FC adapter on workstation / LMS (port 1)
To FC adapter (port 2)
Cabling for additional enclosures
