9
R E P L A C E M E N T P A R T S
1 1 12V Motor (Power Drive #'s 719527 90-33319
716527
1 1 12V Motor (Power Drive #'s 719627 90-33295
716627 )
1 1 24V Motor (Power Drive #'s 719537 90-33320
716537)
1 1 24V Motor (Power Drive #’s 719637 90-33318
719630, 719632)
2 2 Flanged Nuts, 1/4 -20 90-23149-02
8 1 Splash Cover (Power Drive #'s 60-33291-01
719537, 716537)
8 1 Splash Cover (Power Drive # 60-33302-01
719630
8 1 Splash Cover with Screws 61-17315
(Power Drive #'s 716527,
716627, 716727, 719527, 719621,
719627, 719631, 719637, 719727)
9 2 Self-tapping Cover Screw 60-23039-12
10 3 5/16 UNC Grade 5 or Better Not Supplied
Mounting Bolts and Washers
1 1 12V Motor (Power Drive #’s 716727 90-33294
719727)
M A I N T E N A N C E A N D R E P A I R
Periodically check the tightness of mounting bolts and electrical connections.
Remove any dirt or corrosion that may have accumulated on the electrical
connections.
Repairs should be done by Authorized Superwinch Repair Centers ONLY. Do
not attempt to disassemble the gearbox. Disassembly will void your warranty.
LUBRICATION
The gearbox is lubricated and sealed for life. If re-lubrication is necessary
(following repair or disassembly), the gearbox should be filled with 5 ounces
of Mobil SHC 630 lubricant or equivalent.
) )
