2

3

become

trapped

in the

hook,

you

could lose

your

finger.

ALWAYS USE THE

HANDSAVER

wire

rope

in

or

out (See

Figure 2).

10. NEVER HOOK THE WIRE ROPE

BACK ONTO ITSELF because you
could damage the wire rope.
Use a nylon strap (Figure 3).

11. It is a good idea to lay a heavy

blanket or jacket over the wire

rope near the hook end when
pulling heavy loads (Figure 4). If
a wire rope failure should occur,
the cloth will act as a damper
and help prevent the rope from
whipping.

13. Your winch is not intended for

overhead hoisting operations.

14. AVOID CONTINUOUS PULLS

FROM EXTREME ANGLES as this
will cause the wire rope to pile
up on one end of the drum
(Figure 5). This can jam the wire
rope in the winch, causing dam-
age to the rope or the winch.

15. NEVER OBSCURE THE WARNING

INSTRUCTION LABELS.

16. Always operate winch with an

unobstructed view of the winch-
ing operation.

17. Equipment such as tackle,

straps,

etc.

winching

periodically inspected

for

that could reduce

18. NEVER RELEASE FREESPOOL

CLUTCH WHEN THERE IS A

ON THE WINCH.

19. NEVER WORK ON OR AROUND

THE WINCH DRUM WHEN

IS UNDER LOAD.

20. DO NOT OPERATE WINCH

UNDER THE INFLUENCE OF DRUGS,

ALCOHOL OR MEDICATION.

Wrong

Right

Figure 3

Figu re

4

Figu re 2

Your winch is a very powerful
machine. If used unsafely or
improperly, there is a possibility
that property damage or personal
injury could result.

The responsibility
for safe installa-

tion and operation of the winch and
prevention of personal injury and
property damage ultimately rests
with you, the operator. There is
no substitute for the use of good
judgement and caution in operating
a winch.

The wire rope

may break before

the winch stalls.

1. Maximum working load capacity

is on the wire rope layer closest
to the drum. DO NOT OVER-
LOAD. DO NOT ATTEMPT PRO-
LONGED PULLS AT HEAVY
LOADS. Overloads can damage
the winch and/or the wire rope
and create unsafe operating con-
ditions.

The vehicle engine should be
running during winch opera-
tion.
If considerable winching is
performed with the engine off,
the battery may be too weak to
restart the engine.

4.

ROPE, HOOK AND WINCH. IN THE

UNLIKELY EVENT OF ANY COM-

PONENT FAILURE IT‘S BEST TO BE

OUT OF HARM‘S WAY.

5. INSPECT WIRE ROPE, STRAPS AND

Always replace wire rope with

the manufacturer‘s identical

replacement part (S

ee Replacement

Parts List).

Periodically check the winch

installation to ensure that all

bolts are tight.

6. USE HEAVY LEATHER GLOVES

when handling wire rope. DO

NOT LET WIRE ROPE SLIDE

THROUGH YOUR HANDS.

7. NEVER WINCH WITH LESS THAN 5

TURNS of wire rope AROUND THE

WINCH DRUM since the wire rope

end fastener may NOT withstand

full load.

WARNING

!

WARNING

!

G E N E R A L S A F E T Y

I N F O R M AT I O N

Figure 5

2. AFTER READING AND UNDER-

STANDING THIS MANUAL, LEARN

TO USE YOUR WINCH.

After installing the winch,

practice using it so you

will be familiar with it

when the need arises.

3. DO NOT “move” your vehicle to

assist the winch in pulling the

load. The combination of the

winch and vehicle pulling togeth-

er could overload the wire rope

and the winch.

8. KEEP CLEAR OF WINCH, TAUT STRAP

WIRE ROPE AND HOOK WHEN

OPERATING WINCH.
Never put your finger
through the hook. If
your finger should

when

guiding the

12. NEVER USE YOUR

WINCH FOR LIFTING

OR MOVING PEOPLE.

a

9. Keep Hands away from PINCH

POINTS (Figure 1).

EQUIPMENT FREQUENTLY. A FRAYED

STRAP OR WIRE ROPE WITH BROKEN
STRANDS SHOULD BE REPLACED
IMMEDIATELY.

should be sized

task and should

hooks,

to the

be

damage

their strength.

LOAD

WINCH

WHEN

ALWAYS STAND CLEAR OF STRAPS,

WIRE

OR

Figure 1

Right

Wrong

winch.

Right

Wrong
