71 Chapter 3
Removing the Speaker Set
1. See “Removing the Battery” on page 50.
2. See “Removing the Middle Cover” on page 54.
3. See “Removing the Keyboard” on page 61.
4. See “Removing the Floppy Disk Drive Module” on page 65.
5. See “Removing the VGA Thermal Plate” on page 66.
6. See “Removing the CPU Heatsink Plate” on page 66.
7. See “Removing the Second Fan Bracket” on page 67.
8. See “Removing the HDD Bracket” on page 68.
9. See “Removing the Main Board” on page 68.
10. See “Removing the DC Board” on page 69.
11. Tear off the tape fastening the speaker set cable. Then remove the four screws that secure the speaker
set. Remove the speaker set from the lower case.
