Southern Folger 10300P PNEUMATICALLY OPERATED DEADLATCH User Manual
Application, Function
10300P-1: KEYED ONE SIDE
10300P-2: KEYED BOTH SIDES
APPLICATION:
Minimum to medium security
swinging doors that are to be
unlocked from a remote
location. Jamb mounted.
Door position indicator switch,
door closer and heavy duty
door pull are recommended.
FUNCTION
:
ELECTRIC - Remote switch
activates a pneumatic air
cylinder which retracts the
latchbolt. Latchbolt remains
retracted until door is opened
approximately 2", then it
releases, automatically latches
and deadlocks when the door is
closed.
MECHANICAL - Latchbolt is
retracted with a builder’s
hardware key at the door, and
remains retracted until door is
opened approximately 2", then
it releases, automatically
latches and deadlocks when the
door is closed.
10300P
PNEUMATICALLY
OPERATED
DEADLATCH
P N E U M A T I C L O C K S
JAMB MOUNTED FOR
SWINGING DOORS
Minimum and medium security.
SS Rev. 04-14
C5
For more information, please call 210.533.1231.
