F4
A C C E S S O R I E S
INSTITUTIONAL
HINGES
204FMSS FULL MORTISE HINGE
204FMSS
INSTITUTIONAL HINGES
APPLICATION:
For swinging hollow metal doors.
Each hinge features cast
stainless steel leaves with
integral security stud and
non-removable stainless steel
pin. Security fasteners are
provided with each unit.
TECHNICAL DATA:
• STANDARD FINISH:
Stainless steel - US32D
• SIZE: 4-1/2" x 4-1/2" x 3/16"
• WEIGHT: 1.5 lbs.
• HINGE LEAVES:
Cast stainless steel
• HINGE PIN: Stainless steel
• ASTM F1758 Certified
Impact Test-Grade 1
