1.
Push the four casters firmly into the holes in each corner of the bottom
shelf. Important: casters must be fully seated. Tap firmly with rubber
mallet to properly seat casters.
4.
Slide runners onto the legs and tighten down to desired height. Align
holes on the shelf adapters to the holes on the bottom of the keyboard
and attach using six sheet metal screws. Slide the rear of the shelf
adapters under the tab on the back of the runners and snap the front of
the shelf adapters onto the back tongue on the front of runners.
IMPORTANT: Electric Assembly should
be assembled first.
Align cord bracket to the pre-drilled holes on the underside
of the middle and attach using two silver screws.
5.
Insert the leg post on the top shelf into the smaller legs.
2.
Insert longer legs onto the leg post on the bottom shelf and firmly
hammer until properly seated. Then insert the leg post on the middle
shelf into the legs.
Model OHT42PS
3.
Push smaller legs onto the leg post on the middle shelf.
PLACE LOCKING CASTERS
AS ILLUSTRATED
TAB
SHELF RUNNER
ADAPTER
ELECTRIC ASSEMBLY
SCREWS
LOCKING TONGUE
Allen head set
screw & wrench
Set shelf height as
desired then tighten
Allen head set
screws to secure
Allen head set
screw & wrench
Allen head set
screw & wrench
OHT42PS
1 - Top shelf w/handle
1 - Middle shelf w/8 leg posts
1 - Bottom shelf w/caster sockets
1 - Set short legs
1 - Set long legs
4 - Casters (2 w/brake)
1 - Electric assembly
1 - Cord wrap
1 - Keyboard
1 - Runner
Tools Required:
Rubber mallet
Parts List
