WPA-6101 300Mbps Wireless Ceiling Gigabit PoE Access Point
LED Description
Status
Change Master Mode / Slave Mode
When System is ready: (without click button.)
Status LED in Solid : In Master Mode
Status LED in Flash: In Slave Mode
1.Press Reset/WEC button 3 sec to trigger WEC or Reset_WEC function; Status
LED flash very fast during this period
2.Press Reset/WEC button 5~10 sec till WiFi Dark then release Button to
change Mode . Status LED flashes per 0.5 during this period.
3.Press Reset/WEC button 10 ~ 15sec WEC config status release.
Status LED flashes per 1 sec during this period
4.Press Reset/WEC button 15 sec to reset to default. Status LED will be blink
during this period then device reboot.
Light Off: The device is power-off
WiFi
Green in flash: data packet transferred.
Green in very flash per second during 2min:WPS PBC status
When press Reset /WEC Button about 5~10 sec,then WiFi LED will be dark
about 20 sec then blink.
Dark: Wireless Radio is disable
LED in Slow flash: Wireless Connection doesn't establish.
LED in Solid : Wireless Connection established successfully.
LAN LED in flash: data packet transferred
1.2.5 Button Indicators
Button Description
Rese/WEC
(Wireless
Easy
Connection)
Button for Reset and WEC Functions
1.Press Reset/WEC button 3 sec to trigger WEC or Reset_WEC function;
Status LED flash very fast during this period
2.Press Reset/WEC button 5~10 sec till WiFi Dark then release Button to
change Mode .Status LED flashes per 0.5 during this period.
3.Press Reset/WEC button 10 ~ 15sec WEC config status release.
Status LED flashes per 1 sec during this period
4.Press Reset/WEC button 15 sec to reset to default. Status LED will be
blink during this period then device reboot.
