Class of Service: Physical port, 802.1p
There are 2 types of CoS for this setting; 802.1p and physical port. The user can select
more than one item for each port.
Please note that if more than one type of CoS is selected, the switch will arrange the
packet to the assigned queue according the following priority:
1st
802.1p
2
nd
physical port
For 802.1p priority, the following table is used to map the 802.1p field to the priory
queue.
Security Filter
FSW-1671 provides MAC Address Binding security filter.
MAC Address Binding
Port No: Displays the port number being assigned the MAC addresses.
MAC Address: Users can assign up to 3 MAC addresses to the port.
Read: Pull down the selection bar to choose a port number and click the read button to
show the MAC addresses bound with the port or modify the MAC addresses.
Priory Field Priority Queue
6, 7 Q4
4,5 Q3
0,3 Q2
1,2 Q1
