Technical Specifications
General
Model
WBR-6603 150Mbps Wireless ADSL2+ Modem Router
Data Transfer Rate
1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54Mbps
Max physical rate up to 150 Mbps in 802.11n mode
Transmit Power
802.11b: 17±2dBm
802.11g: 14±2dBm
802.11n: 14±2dBm
Frequency Range
America/ FCC: 2.412~2.462GHz (11 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Modulation Schemes
DBPSK/DQPSK/CCK/OFDM
Channels
1~11 channels (FCC), 1~13 channels (ETSI),
Security
64/128-bits WEP Encryption, WPA-PSK, WPA2-PSK, WPA, WPA2, 802.1x
Diagnostic LED
Status
ADSL
WLAN
LAN LEDs
Antenna
2dBi Dipole fix antenna
Physical and Environmental
Operating Systems
Supported
Windows 2000, Windows XP, Windows Vista, Windows 7, Linux, MAC OSX
Temperature
Operating: 0
° ~ 40° C, Storage: -10° ~ 70° C
Humidity
10% ~ 90% RH, no condensation
Dimensions
150mm (L) x 110mm(W) x 28mm (D)
Certifications
FCC, CE, Wifi Certificate
