1
MODEL
174298.00
174299.00
MAX ARMATURE
CURRENT (AMPS DC)
120*
100**
1 MIN. PEAK ARMATURE
CURRENT (AMPS DC)
250
240
MAX ARMATURE
VOLTAGE (VDC)
12 or 24 1
36 or 48 1
DC INPUT VOLTAGE
RANGE (VDC)
10 - 32
20 - 62
Specifications
Acceleration Time Range 0.2 - 20 seconds
Deceleration Time Range 0.2 - 20 seconds
Analog Input Voltage Range (Signal Common must be same as battery common) 0 - 5 VDC
Input Impedance (S1 to S2) 520 K
Speed Regulation 1%
Speed Range 100:1
Form Factor 1.01
Ambient Operating Temperature Range 0° C - 40° C
Weight
174298.00
2.25 lbs
174299.00 2.25 lbs
Vibration 0.5G max (0 - 50 Hz)
0.1G max (>50 Hz)
* Derate by 15% when mounted horizontally.
** Derate by 20% when mounted horizontally.
1 0 - 100% of Input Voltage.
