LEESON Chassis Mount PWM Control: M1740009.00 - Manual (Page 7)

1
Specifications
Model M1740009.00
AC Line Voltage 115 VAC, ±10%, 50/60 Hz, single phase
Horsepower Range (with 130 VDC motors) 1/20 - 1/3 HP
Armature Voltage 0 - 130 VDC
Maximum Continuous Armature Current 2 ADC
Form Factor (at base speed) 1.05
Acceleration Time (with load) 1 second
Deceleration Time (with load) 2 seconds
Analog Input Voltage Range
(isolated; S1 to S2) 0 - 5 VDC
Input Impedance (S1 to S2) > 100K ohms
Speed Regulation 1% of base speed or better
Ambient Temperature Range 10°C - 40°C
Weight 0.6 lbs
