10 American Dryer Corporation 450569 - 5
Wrapper Assembly
Illus. No. Part No. Qty. Description
1 150309 20 #10-16 x 1/2” Hex Head TEK Crimptite Screw
2 859367 1 Bottom Right Wrapper
3 –––––– 1 Idler Shaft
(refer to Idler Shaft Assembly on page 14)
4 –––––– 1 Temperature Sensor Bracket
(refer to Temperature Sensor Bracket Assembly on page 9)
5 859368 1 Bottom Left Wrapper
6 –––––– 1 Drive Shaft
(refer to Drive Shaft Assembly on page 15)
7 122116 1 Lint Door Switch – 24 VAC
