General
Description
The C-UL-US listed SST–2 Fixed Set Point Thermostats replace
electromechanical thermostats in cost-sensitive applications requiring ground fault
equipment protection (GFEP). The SST is classified to UL and CSA safety standards
by UL for use in temperature-regulation applications. It is the ideal low-cost
thermostat for areas not subject to mechanical abuse.
4 1/4"
(108mm)
1 1/16”
(27mm)
Conduit Entry
3/8" (10mm) Ø
Temperature Sensor
1 7/16"
(37mm)
20' (6m)
Sensor Cable,
3/16" (5mm) Ø
7 7/16"
(189mm)
1 1/16”
(27mm)
Conduit Entry
Figure 1: SST–2 dimensions. See Appendix A.
