King Electric SRK10 splice/tee kit - Manual (Page 4)

Rev 9.15.12 www.king-electric.com 4
Remove release paper from mastic strip and wrap the
mastic around the outer jacket as shown. Do this to all
the cables to be spliced.
11
Wrap a second piece of mastic around the end of the
cable as shown. Pinch the center of the mastic to seal
the conductive core.
12
13 14
Twist the braided ground pigtails together.
15
Immediately pinch the tube with pliers between the
bus wires while it is still hot and hold for 10 seconds.
Make sure the heat shrink tube is completely sealed
between the bus wires with no visible gap.
Carefully align the heating cable sections and place
them together, press mastic strips firmly together.
Fasten with a cable ties at each of the two positions
shown (10-
3/4” and 7-3/4”).
Place the un-insulated connector provided on the
ground wires.
16
