JuiceGoose P90 Series - Manual (Page 43)

P90 USER’S MANUAL UNINTERRUPTIBLE POWER SUPPLY (UPS)
Xtreme Power Conversion Corporation (Rev 8/29/13) Page 43
120V MODEL P90-1000 P90-1500 P90-2000 P90-3000
PHYSICAL
Dimensions
W x D x H
17.24 x 14.96
x 3.5 in
(438 x 380 x
88 mm)
17.24 x 18.9 x 3.5 in
(438 x 480 x 88 mm)
17.24 x 23.62
x 3.5 in
(438 x 600 x
88 mm)
Unit Weight
29.1 lbs
(13.2 kg)
41.67 lbs
(18.9 kg)
45.42 lbs
(47.29 kg)
65.7 lbs
(29.8 kg)
Line Cord
6 ft (1.8 m)
5-15P 5-20P L5-30P
Receptacles
(with Programmable
load segment)
(8) 5-15/20R
(1) L5-30R +
(4) 5-15/20R
Network
Protection
Modem / phone / fax / network in/out for surge protection
Communication
Interface
RS-232 and USB with Intelligent slot for
Web/SNMP (optional card) or AS400 (optional card)
Included in Box
ViewPower CD, horizontal brackets (front),
tower stand brackets, 4-post rail kit, 4ft USB cable, manual
ENVIRONMENTAL Temperature
32-104°F (0 - 40°C)
Humidity 0 – 95% Non-Condensing
Audible Noise < 45dba @ 1 meter
Altitude 11,500 ft (3500 m) above sea level
Warranty Three years electronics / Three years batteries
Approvals UL 1778, cUL, FCC
Indicators &
Alarms
LCD Visual Display
Programmable / Rotatable Display with Input / Output
Voltage & Frequency, Online mode, Backup mode, Battery
capacity, Load level
Buttons On / Mute; Select; Off / Enter
Audible Alarm
Low battery, Overload, Battery not connected, Overcharge,
Site wiring fault, EPO mode, Fan failure, Over temperature,
Charger failure, Battery fault
