14
LP-374 REV. 3.25.14
3. High Temperature Setting
If the temperature set by user or actual temperature is above 120
o
F, this icon lights. This icon will shut off if water temperature is less
than 120
o
F, or when the display is in screen save mode.
4. Lock Icon
This icon lights when the key pad is locked, and will shut off when the key pad is unlocked.
5. Alarm Icon
The alarm icon will flash and an alarm will sound when the water heater is in error and under protection, and continue to flash and
sound until the reason for the error is solved or the water heater is reset.
6. Vacation
The Vacation icon lights when this feature this feature is in use. Vacation Mode greatly reduces energy usage. See Section E on pages
18 - 19 for more on Vacation Mode.
7. Auto Mode Icon
This icon will flash slowly when the water heater is in Auto Mode. See Section D on page 18 for more on Auto Mode.
8. Economy Mode Icon
This icon will flash slowly when the water heater is in Economy Mode. See Section D on page 18 for more on Economy Mode.
9. Electric Mode Icon
This icon will flash slowly when the water heater is in Electric Mode. See Section D on page 18 for more on Electric Mode.
10. Water Temperature Mode Icon
This icon has three phases:

When water temperature is less than 140
o
F, and set point water temperature is greater than 120
o
F, all three phases will be lit.

When water temperature is less than 120
o
F, and set point water temperature is greater than 110
o
F, the lower two phases will
be lit.

When water temperature is less than 110 o F, and set point water temperature is greater than 100 o F, the lowest phase will be lit.
11. Main Screen
The display will light once the power supply is connected. During normal
usage, this shows water temperature. Error or protection codes are
displayed when the water heater is under error or protection. The main
screen returns to normal when error or protection is cleared. Pressing
ENTER and UP simultaneously will query the water heater. Parameters
display on this screen.
C. SETTING THE WATER TEMPERATURE
The temperature of the water in the water heater can be regulated by
adjusting the temperature setting up or down using the arrow keys on
the control panel.
Consider safety and energy conservation when selecting the water
heater temperature setting. The lower the temperature setting, the greater the savings in energy and operating costs. To comply with
safety regulations, water temperature is factory set at 120
o F. This is the recommended starting set point.
Water temperatures above 125
o
F can cause severe burns or death from scalding. Be sure to read and follow the warnings outlined in
this manual and on the label located on the water heater near the upper element access panel.
Mixing valves for reducing point-of-use water temperature by mixing hot and cold water in branch water lines are available. Contact a
licensed plumber or the local plumbing authority for further information.
There is a hot water scald potential if the water temperature is set too high. Households with small children, disabled, or elderly persons
may require a 120
o
F or lower thermostat setting to prevent contact with scalding water.
To Adjust the Temperature
First, unlock the key pad by pressing and holding the ENTER key for 3 seconds. Next, press the UP or DOWN arrows on the control
panel key pad to increase or decrease the water temperature. If increasing the water temperature beyond 120
o F, a CAUTION triangle
and thermometer icon will appear on the appliance display to warn the user that raising the water temperature also increases scalding
risk.
APPROXIMATE TIME / TEMPERATURE
RELATIONSHIPS IN SCALDS
120
o
F More than 5 minutes
125
o
F 1 ½ to 2 minutes
130
o
F About 30 seconds
135
o
F About 10 seconds
140
o
F Less than 5 seconds
145 o F Less than 3 seconds
150 o F About 1 ½ seconds
155 o F About 1 second
Table 3 – Table Courtesy of Shriners Burn Institute
