Navigation System 55
Map Screen Legend
Acura Dealer
School
Restaurant
ATM
Parking Lot
Post Office
Honda Dealer
Hospital
Grocery Store
Gas Station
Hotel/Lodging
Parking Garage
Freeway Exit Information
Landmark Icon - Generic (see page 63)
Destination Icon (see page 63)
Map Features
NOTE:
If you move the Interface Dial over an area (map
features shown above), the name is displayed on
the screen.
: Park
: Hospital
: Shopping Mall
: Golf Course
: Water Area
: Cemetery
: University
: Indian Reservation
: Airport/Stadium/Business
Map Scale Adjustment
(Mile or km per half inch appears
only when you zoom in or out by
rotating the Interface Dial knob.)
(see page 61)
NOTE:
See
Map Legend on the INFO screen ( Other ) for further explanation (see page 89).
Current Map Scale
(see page 61)
Current Street
(see page 70)
Vehicle Position
(see page 70)
“Breadcrumbs”
(see Off-road Tracking
on page 69)
Direction of Destination (when en route)
(see page 57) Map Orientation
(see page 62)
Distance to Destination (see page 57)
Time to Destination (see page 57)
Waypoint (see page 74)
Blue Line
Calculated route
(see page 54)
Map Menu (see page 57)
(Push in on the Interface Dial to view.)
One-Way Traffic Icon
(1/20 mile scale only) (see page 63)
Streets
(see Map Overview on
page 6, or Unverified Area
Routing on page 101)
Interstates or Freeways
Verified Streets
Unverified Streets
