Harrington Hoists and Cranes Static/Dynamic Hoist Load Tester - Manual (Page 25)

25
Fig.
No.
Name Dwg. No.
Qty. per
Assy.
Notes
0 Tester Frame Assy. cont. 50979 1
35 Link Support 50614 2
36 Hose Clamp 9009901 2
37 Winch 9010701 1
38 Serial Number Plate 80049 1
39 Shackles 9010301 2
40 Chain Particle Restraint Assy. 50788 1
41 Bolt 9093349 2 M10 x 25
42 Bolt 9093124 12 M10 x 40
43 Lock Washer 9012712 12 M10
44 Nut 9093427 12 M10 x 1.5
45 Hook for Chain Particle Rest. 50790 1
46 Nut 9093433 3 M12 x 1.75
47 Lock Washer 9012713 3 M12
48 Pulley Spacer 5099907 6
49 Pulley Bushing 5099906 3
50 Bolt 9093151 3 M12 x 70
51 Pulley Mount R. H. 5099904 1
52 Pulley Mount L. H. 5099901 1
53 Step Assembly 50767 1
54 Washer 9005212 12 3/4
55 Shackle 9010303 1
