Harrington Hoists and Cranes Static/Dynamic Hoist Load Tester User Manual
Page 24
24
4.6 English/Metric Tester Frame Assembly
Fig.
No.
Name
Dwg. No.
Qty. per
Assy.
Notes
0
Tester Frame Assembly
50979
1
1 Top Beam Assembly
50980
1
2 Column Assembly
50955
1
3 Cylinder Mount
50950
1
4 Lower Beam Assembly
50954
1
5 Base Assembly
50554
1
6 Outrigger Assembly
50558
2
7 Pin
5055302
3
8 Pin
5055301
2
9 Master Link
9010201
2
10 Master Link
9010202
2
11 Trolley Test Beam Assy.
50973
1
12 "I" Taper Washer
9043522
6
M20
13 Bolt
90931135
6
M20 x 46 x 80
14 Lock Washer
9012717
6
M20
15 Nut
9093445
18
M20 x 2.5
16 Bolt
9093192
22
M16 x 65
17 Flat Washer
9012517
4
M16
18 Lock Washer
9012715
18
M16
19 Nut
9093439
22
M16 x 2.0
20 Rear Mounting Bracket
5099902
2
21 Front Mounting Bracket
5099903
1
22 Bolt
90931135
6
M20 x 46 x 75
23 Capacity Plate
80037
4
24 Label
80048
1
25 Calibration Chart
1
26 Bolt
9004785
16
1/2 - 13 x 1 1/4
27 Lock Washer
9005313
16
1/2
28 Flat WAsher
9012515
16
M12
29 Nut
9003905
16
1/2 - 13
30 Plain Caster
9007203
2
31 Swivel Caster
9007202
2
32 Bolt
9093106
10
M8 x 60
33 Lock Nut
9098506
10
M8 x 1.25
34 U Taper Washer
9043418
10
M16
