Outputs:
Note that only the second two channels of the J6 output gets changed by the
installation of a Quad Piggyback D/A card:
wire number color wire function
1 brown circuit ground
2 red channel 0 data bit 7
3 orange channel 0 data bit 6
4 yellow channel 0 data bit 5
5 green channel 0 data bit 4
6 blue channel 0 data bit 3
7 violet channel 0 data bit 2
8 gray channel 0 data bit 1
9 white channel 0 data bit 0
10 black +15 VDC unregulated power supply (fused for 1 amp)
11 brown circuit ground
12 red channel 1 data bit 7
13 orange channel 1 data bit 6
14 yellow channel 1 data bit 5
15 green channel 1 data bit 4
16 blue channel 1 data bit 3
17 violet channel 1 data bit 2
18 gray channel 1 data bit 1
19 white channel 1 data bit 0
20 black +15 VDC unregulated power supply (fused for 1 amp)
TTL level test data input:
21 brown circuit ground
22 red TTL LEVEL TEST DATA INPUT bit 7
23 orange TTL LEVEL TEST DATA INPUT bit 6
24 yellow TTL LEVEL TEST DATA INPUT bit 5
25 green TTL LEVEL TEST DATA INPUT bit 4
26 blue TTL LEVEL TEST DATA INPUT bit 3
27 violet TTL LEVEL TEST DATA INPUT bit 2
28 gray TTL LEVEL TEST DATA INPUT bit 1
29 white TTL LEVEL TEST DATA INPUT bit 0
30 black +15 VDC unregulated power supply
J6/A analog output:
31 brown circuit ground
32 red +15 VDC unregulated power supply
33 orange + channel 3 output data
34 yellow - channel 3 output reference
35 green + channel 2 output data
36 blue - channel 2 output reference
37 violet + channel 1 output data
38 gray - channel 1 output reference
39 white + channel 0 output data
40 black - channel 0 output reference
