Gilderfluke&Co Quad EFB Controller User Manual
Page 5
If any channels are left unused on the EFB-Quad or PID-Quad controller, you will need
to short together the transducer inputs on the unused channels to turn the ERROR LED off.
Installation:
Connections for channel 0 output shown. All other channels are identical.
R
ED
G
REEN
W
HITE
Y
ELLO W
A
IR
O
R
H
YDRAULIC
S
UPPLY
Hydraulic or
Pneumatic
Servo Valve
C2
C1
E
XHAUST
(or R
ETURN
L
INE
F
O R
H
YDRAULICS
)
N/C
10
K
O
HM
R
ESISTANCE
(T
YPICAL
)
CYLINDER
TRANSDUCER
S
TRAIN
G
UAG E
(if using
C
O M PLIANCE
)
The cylinder can be virtually any type of double acting cylinder available (rotary, linear, etc.). The
stroke and diameter of the cylinder can be used to determine the size of valve you need to use by
G
ILDERFLUKE
& C
O
. • 205 S
OUTH
F
LOWER
S
T
. • B
URBANK
, C
ALIF
. 91502-2102 • 818/840-9484 •
FAX
818/840-9485
5 of 12
