D-4 MAINTENANCE D-4
NAMEPLATES / WARNING DECALS MAIN-
TENANCE
Whenever routine maintenance is performed on this
machine - or at least yearly - inspect all nameplates
and labels for legibility. Replace those which are no
longer clear. Refer to the parts list for the replacement
item number.
WELDER / GENERATOR MAINTE-
NANCE
STORAGE
Store the AIR VANTAGE® 500 CUMMINS in a clean,
dry protected areas.
CLEANING
Blow out the generator and controls periodically with
low pressure air. Do this at least once a week in par-
ticularly dirty areas.
bRUSH REMOVAL AND REPLACEMENT
It is normal for the brushes and slip rings to wear and
darken slightly. Inspect the brushes when a generator
overhaul is necessary.
Do not attempt to polish slip rings while the
engine is running.
------------------------------------------------------------------------
GFCI RECEPTACLE TESTING AND RESET-
TING PROCEDURE
The GFCI receptacle should be properly tested at
least once every month or whenever it is tripped. To
properly test and reset the GFCI receptacle:
• If the receptacle has tripped, first carefully remove
any load and check it for damage.
• If the equipment has been shut down, it must be
restarted.
• The equipment needs to be operating at high idle
speed and any necessary adjustments made on the
control panel so that the equipment is providing at
least 80 volts to the receptacle input terminals.
• The circuit breaker for this receptacle must not be
tripped. Reset if necessary.
• Push the "Reset" button located on the GFCI recep-
tacle. This will assure normal GFCI operation.
• Plug a night-light (with an "ON/OFF" switch) or other
product (such as a lamp) into the GFCI receptacle
and turn the product "ON".
• Push the "Test" button located on the GFCI recepta-
cle. The night-light or other product should go
"OFF".
• Push the "Reset" button, again. The light or other
product should go "ON" again.
If the light or other product remains "ON" when the
"Test" button is pushed, the GFCI is not working prop-
erly or has been incorrectly installed (miswired). If
your GFCI is not working properly, contact a qualified,
certified electrician who can assess the situation,
rewire the GFCI if necessary or replace the device.
AIR VANTAGE® 500 CUMMINS
WARNING
Table D.1 Engine Maintenance Components
ITEM MAKE PART NUMbER SERVICE INTERVAL
Air Cleaner Element Donaldson P822768 Replace as indicated by
Service Indicator
Fleetguard AF25436
Oil Filer Cummins C6002112110 Replace every 750 hours or 3 months,
Fleetguard LF16011 whichever is less.
Fan Belt Cummins C0412021749 Inspect every 1000 hours or 12 months,
whichever is less.
Fuel Strainer Cummins 3826094 Inspect and replace monthly as
Fleetguard FF5079 required. Replace annually.
Fuel Filter / Fleetguard FS19594 Replace every 500 hours or 6 months,
Water Separator whichever is less.
Battery ----- BCI GROUP 34 Inspect every 500 hours
Engine Oil Change See Manual ----- Change every 750 hours or 3 months,
whichever is less. Check daily.
